Metal Single Crank Shaft Pneumatic Punch Machine For Hardware Stamping

Brand Name : QIAOSEN

Slider adjustment amount : 100mm for junction box making machine

brand name : Qiaosen

Slider strokes length : 200mm for power press macine

weight (t) : 16

Slider strokes per minute : 20-50SPM for metal stamping machine

Air pressure : 6kg/cm^2

Packaging Details : Standard

machine type : Punching Machine

MOQ : 1

Payment Terms : T/T

core components : Bearing, Pump, Motor, PLC, Other

place of origin : Jiangsu, China

machinery test report : Provided

motor power (kw) : 15

Down platform area : 1250*800*140mm

Supply Ability : 30 Sets/Month

cnc or not : Normal

video outgoing-inspection : Provided

Up platform area : 990*550*90mm for battery case stamping

Delivery Time : 30-90

voltage : 380

Place of Origin : China

Main motor power : 15*4kw*p

Die shut height : 460mm for hole punching machine

Price : $42,000/pieces 1-9 pieces

slide stroke (mm) : 200

key selling points : High-Accuracy

dimension(l*w*h) : 2315*1400*3670

Impact force location : 6mm for metal stamping

Certification : CE / ISO14001

Model Number : ST-80

warranty : 1 Year

Slider adjust device : Manual operation

power source : Pneumatic

model number : ST-60V

Contact Now

Specification
product name
punching machine
Mode
ST-160V
ST-160H
Impact force location
6mm
3mm
Slider strokes per minute
20-50SPM
40-70SPM
Slider strokes length
200mm
90mm
460Die shut height
460mm
510mm
Slider adjustment amount
100mm
Up platform area
990*550*90mm
Down platform area
1250*800*140mm
Shank hole
ᶲ65
Main motor power
15*4kw*p
Slider adjust device
Manual operation
Air pressure
6kg/cm^2
Punch precision level
JIS 1
Overall dimension
2315*1400*3670mm
Product Description

1.The high-strength fuselage structure has small deformation and high precision. 2. OMPI pneumatic dry clutch brake 3.The slider adopts 2corner and 6sided guides 4.The slider guide adopts"high-frequency quenching" and "rail grinding process",which has small wear, high precision,long precision maintenance time and improve service life. 5.Crankshaft is made of high strength alloy 42CrMo, which is 1.3 times stronger than 45 steel 6.The copper sleeve is made of tin phosphor bronze ZQSn10-1,which is 1.5 times stronger than ordinary BC6 brass. 7. Highly sensitive hydraulic overload protection device protects the press and die service life 8.Optional mat (air cushion)

Metal Single Crank Shaft Pneumatic Punch Machine For Hardware Stamping
Metal Single Crank Shaft Pneumatic Punch Machine For Hardware Stamping
Warranty And Service
Metal Single Crank Shaft Pneumatic Punch Machine For Hardware Stamping

Warranty and service:

  • 1. One year warranty for whole press machine.
  • 2. All spare parts are available as most of the parts produced by our factory.
  • 3. It is easy to get the electric parts as all are international famous brands.
  • 4. We can provide technical training and consulting via email, phone or video.
  • 5. We can send out engineers for service, installation or training with reasonable additional cost.
  • 6. English operation and maintenance manual is provided with the press.
  • 7. Certificate of conformity will be sent with press
Company Profile
Metal Single Crank Shaft Pneumatic Punch Machine For Hardware Stamping

Dongguan Qiaosen Machinery Co.,Ltd which have our own factory located in Jiangsu province, established in 2016,Closed to shanghaicity and transportation is very convenient, a birth place of creative minds and gifted talents.

Our factory took the lead in passed authentication of the ISO9001:2008 quality management system . A factory specialized in the production of hydraulic press machine. Mainly products 10 tons to 2000 tons press machine with 8 series, have more than 100 types, link single column, four column, c frame, h frame and all kinds of press machine, punching machine, folding machine, cutting machine, is used in aviation, space flight, automobile, ship, light appliance, daily used hardware and so on. All along, the company products with exquisite design, reasonable price, excellent quality and efficient after-sales service and technical support, received the affirmation of customers at home and abroad, sell well in more than 20 domestic provinces, cities and districts, and exported to United States, Japan, Russia, European Union, southeast Asia, the Middle East and other countries.

Certifications
Metal Single Crank Shaft Pneumatic Punch Machine For Hardware Stamping
Packing & Delivery
Metal Single Crank Shaft Pneumatic Punch Machine For Hardware Stamping
Metal Single Crank Shaft Pneumatic Punch Machine For Hardware Stamping
Metal Single Crank Shaft Pneumatic Punch Machine For Hardware Stamping
FAQ
1. Who are we?
A: Our factory is located in Wuxi, China with a branch company in Dongguan , start from 2016 sell to Southeast Asia(50.00%),Mid East(30.00%),Africa(10.00%),South Asia(5.00%),Northern Europe(4.00%),Eastern Europe(1.00%). There are total about 51-100 people in our office.
2. Why select us?
A: We are high end quality punching machine manufacturer and we promise customers will never regret if they choose our brand.
3. How about your delivery time?
A: Usually it takes about 25 to 40 working days after receiving your advance payment.
4. Do you provide after-sale service?
A: Our technical and quality team will support you any time if you need us.
5. Can i do different color machine?
A: Yes, we can customize your own colors to match your production line
6. Can the touch screen board language change to others
A: Yes, we can do it according to your requirement like Spanish, French ect...
